Detail Text Description
A technical drawing showing the details of a conduit support system installed on an existing roof. The drawing features two views, a front elevation view on the left and an isometric view on the right. Both views depict a galvanized rigid steel conduit held in place by a U-shaped conduit strap fastened with screws to a pipe block. The pipe block has an insulation buffer layer and is based on an SP Products ‘Quick Pipe’ block design. This block sits directly on the roof surface. Annotations in the drawing label various components, such as the ‘conduit strap fastened with screws to pipe block,’ ‘galvanized rigid steel conduit,’ and ‘pipe block with insulation buffer layer.’
