Detail Text Description
Two detailed technical diagrams illustrating a power and furniture interface setup. On the left, a modular furniture leg is shown positioned next to an in-floor junction box. An armored power connection whip extends from this box, designed by the furniture manufacturer. The connection is labeled as being managed by an electrical contactor. The base of the furniture leg is broad and rectangular, supporting the vertical structure.
On the right, a similar modular furniture leg is depicted. This part of the diagram focuses on the interface of power connections with the furniture system, to be executed per the manufacturer’s instructions. A conduit or wiring pathway is detailed as indicated on the power riser, running along the floor surface.
