Detail Text Description
An architectural schematic detailing power pole connections and features several technical drawings. At the top left is an isometric view showing a connection at a beam with components like a 4″x4″ J-box, a Unistrut channel, an angle, and a slotted hole with a spaced bolt. The top right shows the section view of a service pole with dimensions for structural beam placement, angle fitting, and closure strips. It marks duplex grounded receptacles at specific heights. The middle left depicts a horizontal section of the service pole, highlighting spaces for 120V wires and receptacle placement. The lower left includes a floor base plan illustrating the layout of holes for carrying wires from underfloor ducts. The lower right shows a side section at floor level, featuring the underfloor duct and base positioning. Each section is labeled with dimensions and specifics about construction.
