26054322 – 8x6x7 Pre-cast Telecommunications Manhole

A detailed construction schematic for an 8′ x 6′ x 7′ pre-cast telecommunications manhole. It includes a plan view and section view labeled “A-A” depicting the layout and specifications. The plan view shows dimensions and key elements like pocket pulling irons, keyways, and hardware placements. The section view illustrates features including a galvanized steel ladder, copper ground bar, and lateral knockouts. Annotations provide specific measurements and instructions, such as the reinforcement and concrete strength. Various components like “S” brackets, “B” brackets, and the E.J.I.W. #1805 heavy-duty frame and cover are specified, alongside instructions for installation, waterproofing, and duct placement.
