26510007 – Inner Lamp Switch Dim Detail (type F ) F Fixtures

A technical diagram illustrating the wiring details for inner lamp switching and dimming. At the top left, labeled “N” and “L,” two arrows point to a 120 VAC line, indicating the electrical power supply. The wiring connects to a rectangular box labeled “LITHONIA EQUINOX LEQ-LC MODULE.” From this module, wires extend to two separate boxes labeled “MARK VII,” which are connected in parallel. Each box is linked to additional wires that lead towards the right, labeled “TO ADDITIONAL MARK VII BALLASTS.” Multiple lines labeled “BELDEN #8770 CABLE” run from the bottom of the LEQ-LC module to another rectangular boxlabeled “LITHONIA EQUINOX LEQ-MC1 CONTROL.” A horizontal line across the diagram is noted as the “DROP CEILING LINE.” At the bottom, the title “INNER LAMP SWITCHING/DIMMING DETAIL” is written above the tag “NO SCALE.” A note box at the lower right states: “THE MARK VII BALLAST IS THE CENTER LAMP BALLAST OF THE FIXTURES.” The diagram ends with a file name or reference number: “26510007.dgn.”
