MS 238245 001 Chilled Beams Piping Schedule

A table titled “Chilled Beam Schedule,” formatted in a grid layout. It is structured with horizontal and vertical lines, creating a matrix of boxes for data entry. The table contains columns with headers such as “TAG,” “SERVICE,” “LENGTH (FT),” “WIDTH (FT),” “AIR INLET DIAMETER (IN),” “ROOM DB (DEG F),” “RH (%),” “AIRSIDE,” “PRIMARY AIR,” “FLOW CFM,” “DB (DEG F),” “WB (DEG F),” “ADP MAX (IN WG),” “CAPACITY (BTU/HR),” “WATER-SIDE,” “EWT (DEG F),” “LWT (DEG F),” “MAX GPM,” “WPD MAX (FT WG),” “CAPACITY (BTU/HR),” “TOTAL CAPACITY (BTU/HR),” “MAX NC,” “AIR VOLUME CONTROL UNIT REFERENCE,” and “REMARKS. Below the headers, a row of dashes indicates placeholder information.
